Explore Defender
Defender
Classic cargo lines that stand the test of time but won’t test your budget.
.jpg)
---edit.jpg)
.jpg)
---edit.jpg)
---edit.jpg)
---edit.jpg)
.jpg)
.jpg)
-
- Double Rear Doors (Opt. Ramp Available)
- Semi Style Camlock Door Latch on Rear Doors
- Door Hold-Backs on All Doors
- Leaf-Spring Axles
- All-Wheel Electric Brakes w/Breakaway*
- 12-Volt Breakaway Switch with Battery*
- Silver Powder Coated Wheels
- Chrome Center Caps
- Radial Tires
- Galvanized Roof
- Colored Aluminum or ATP Top Wrap
- RV Style C/S Door (24" on 5 wide, 32" on 6 wide, 36" on 7 & 8 wide)
- 24" Stoneguard
- 2 – Interior LED Dome Lights, & 1 – Wall Switch
- Roof Vent
- 3/8" Plywood Walls with Lauan Trim
- ATP Exterior Aluminum Fenders
- Radius Fiberglass Front Cap
- Clear Lens LED Clearance Lights
- Clear Lens LED Strip Tail Lights
- .030 Aluminum Exterior
- Colored Aluminum Wrap on Rear
- Undercoated Frame
- Tongue Jack w/ Sand Pad
- Steel Sealed Sidewalls
- Welded Safety Chains
-
- 16" O/C Roof Upgrade
- One-Piece Aluminum Roof
- (2) LED Loading Lights with switch
- (2) Stabilizer Jacks Under Rear Corners
- 6" of ATP Along Exterior Bottom of Sidewalls
-
- Rear Ramp Door
- Beavertail
- 102" Wide Upgrade
- 16" O/C Floor
- (4) LED Dome Lights - (2) Switches (Total)
- (2) Roof Vents (Total)
- (4) 5,000 lb. D-Rings
- Triple Tube Tongue
- Aluminum Roof
-
- 6" ATP on Bottom
- ATP Front Corners
- Anodized Rear Hoop
-
- All 110-Volt Packages require a finished ceiling
- (2) 4' Fluorescent Lights with (1) Wall Switch
- (2) Interior Wall Recepts
- Exterior Wall Recept with GFI
- With Lifeline and Motorbase Plug
- All 110-Volt Packages require a finished ceiling
-
- White Vinyl Ceiling Liner
- White Aluminum Wall Liner
- Vinyl Flooring
- Aluminum Tread Plate on Ramp and Flap
-
- Rear Ramp Door
- One Piece Flat Top Aluminum Roof
- Low Rider Pan in Rear
- Flushlock
- White Vinyl Walls and Ceiling
- V-Nose Front with Anodized Nose
- 4' Overhead Cabinet in V-Nose
- 6-5,000 lb. D-Rings
- Black RTP Floor
- Freezer Latches on Rear Ramp
- 2 - Flow Thru Vents IPO Roof Vents
- Drop Down Corner Post Jacks
- 4 - Recessed LED Dome Lights w/ 2 Switches
- 2 - 12 Volt Loading Lights
- Orange or Gold Flame Graphics
- 24" Smooth Anodized on Sides
- Anodized Rear Hoop
- 2 - Wheel Chocks Shipped Loose
- 81" Overall Exterior Height
-
- 16" O/C Roof
- 16" O/C Floor Members
- 60" Triple Tube Tongue
- 3/4" Plywood Walls
- (2) LED Loading Lights with switch
- (2) 2-Way Sidewall Vents (Aluminum)
- (3) Aluminum Ladder Rack Sections
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (2) Non-Powered Roof Vents
- 48" RV Door Upgrade
- 54" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
- Surface Wall Mount E-Track (1 Row on Each Sidewall)
- Shelf Across Front of Trailer (24" Deep with 3" Lip)
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (1) Non-Powered Roof Vent
- 54" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- 16" O/C Roof Upgrade
- Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (1) Non-Powered Roof Vent (Total of 2)
- 60" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- 16" O/C Roof Upgrade
- Reinforced Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
- Extra Grab Handle on Rear Ramp Door
- 3/4" Plywood Kickplate on Interior Walls
- Surface Mount E-Track on Sidewalls, 1 Row Per Wall
- Locking Hasps on Side and Rear Doors
Specifications
| DE58SA | DE510SA | DE610SA | DE612SA | DE610TA2 | DE612TA2 | DE710TA2 | DE712TA2 | DE714TA2 | DE716TA2 | DE816TA2 | DE818TA2 | DE820TA2 | DE822TA2 | DE824TA2 | |
| GVWR: | 2990 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. |
| Payload Capacity: | 2040 | 1965 | 1790 | 1690 | 5350 | 5200 | 5075 | 4900 | 4725 | 4550 | 4400 | 4250 | 4100 | 3950 | 3800 |
| Exterior Length: | 11' 10" | 13' 10" | 13' 10" | 15' 10" | 13' 10" | 15' 10" | 13' 10" | 15' 10" | 17' 10" | 19' 10" | 19' 10" | 21' 10" | 23' 10" | 25' 10" | 27' 10" |
| Exterior Width: | 7' 0" | 7' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" |
| Exterior Height: | 6' 5" | 6' 5" | 7' 9" | 7' 9" | 8' 3" | 8' 3" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" |
| Interior Length: | 8' 7" | 10' 7" | 10' 7" | 10' 7" | 10' 7" | 12' 7" | 10' 7" | 12' 7" | 14' 7" | 16' 7" | 16' 7" | 18' 7" | 20' 7" | 22' 7" | 24' 7" |
| Interior Width: | 4' 8" | 4' 8" | 5' 8" | 5' 8" | 5' 8" | 5' 8" | 6' 8" | 6' 8" | 6' 8" | 6' 8" | 7' 6" | 7' 6" | 7' 6" | 7' 6" | 7' 6" |
| Interior Height: | 4' 10" | 4' 10" | 6' 2" | 6' 2" | 6' 8" | 6' 8" | 6' 9" | 6' 9" | 6' 9" | 6' 7" | 6' 7" | 6' 7" | 6' 7" | 6' 7" | 6' 7" |
| Rear Door Type: | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double | Double |
| Rear Door Width: | 4' 4" | 4' 4" | 5' 4" | 5' 4" | 5' 4" | 5' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 7' 1" | 7' 1" | 7' 1" | 7' 1" | 7' 1" |
| Rear Door Height: | 4' 2" | 4' 2" | 5' 6" | 5' 6" | 6' 0" | 6' 0" | 6' 1" | 6' 1" | 6' 1" | 5' 11" | 5' 11" | 5' 11" | 5' 11" | 5' 11" | 5' 11" |
| Coupler Size: | 2" | 2" | 2" | 2" | 2-5/16" | 2 5/16" | 2 5/16" | 2-5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" |
| Curb Weight: | 950 | 1025 | 1200 | 1300 | 1650 | 1800 | 1925 | 2100 | 2275 | 2450 | 2600 | 2750 | 2900 | 3050 | 3200 |
| Hitch Weight: | 95 | 103 | 120 | 130 | 165 | 180 | 193 | 210 | 228 | 245 | 260 | 275 | 290 | 305 | 320 |
| Hitch Height: | 17" | 17" | 17" | 17" | 18" | 18" | 18" | 18" | 18" | 20" | 20" | 20" | 20" | 20" | 20" |
| Platform Height: | 17 | 17 | 17 | 17 | 18 | 18 | 18 | 18 | 18 | 20 | 20 | 20 | 20 | 20 | 20 |
| Axle: | 2990 | 2990 | 2990 | 2990 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 |
| Suspension: | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD |
| Brakes: | Optional | Optional | Optional | Optional | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric |
| Tires: | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C |
| Wheels: | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt |
| Main Frame: | 3" Tube | 3" Tube | 3" Tube | 3" Tube | 4" Tube | 4" Tube | 4" Tube | 4" Tube | 4" Tube | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam |
| Floor: | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood |
| Walls: | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood |
