Explore Nomad Aluminum
Nomad-Aluminum
Uncompromised quality in all aluminum frame at an affordable price. Wherever you wander, Nomad will stay behind you.
---Edit.jpg)
-
- All Aluminum Frame
- 24” Wedge Front
- Spring Axle w/EZ Lube Hubs & 4” Drop
- 15" Steel Belted Radial Tires
- Silver Powder Coated Wheels
- Aluminum Frame Rear Double Doors
- Bonded .030 Aluminum Exterior
- One Piece Aluminum Roof
- 3/4” Premium Grade Plywood Floor
- 3/8” Premium Grade Plywood Walls
- RV Style Door With Flushlock (24” on 5’ Wide, 32" on 6 wide, 36" on 7 & 8 wide)
- 16” O/C Wall Studs
- 24” O/C Floor & Roof Studs
- (1) LED Interior Dome Light
- LED. Exterior Lights
- Side Wall Vents
- 2K Tongue Jack
- 16” ATP Stoneguard
- Sealed Side Walls
- 8’ 6” Wides Include
- 16” O/C Floors & Roof
- Triple Tube Tongue
- Ramp Door With Beavertail
- 36” RV Style Door With Flushlock
- 1 Extra LED Dome Light (2 Total) W/ 1 Wall Switch
- 1 Roof Vent ( In Addition To Side Wall Vents)
-
- 24" Aluminum Tread Plate Stoneguard Upgrade
- 1 - LED Dome Light (total of 2)
- 1 - 12 Volt Switch for LED Domes
- 1 Pair Stabilizer Jacks
-
- Rear Ramp Door
- 24" Aluminum Tread Plate Stoneguard Upgrade
- 1 - LED Dome Light (total of 2)
- 1 - 12 Volt Switch for LED Domes
- 1 Pair Stabilizer Jacks
-
- 24" Aluminum Tread Plate Stoneguard Upgrade
- 3 - LED Dome Light (total of 4)
- 2 - 12 Volt Switches for LED Domes
- 16" O/C Floor Crossmembers
-
- 6" Extra Height
- Rear Ramp Door
- 1 Pair Stabilizer Jacks
- 4-Surface Mount D-Rings
-
- 16" O/C Roof
- 16" O/C Floor Members
- 60" Triple Tube Tongue
- 3/4" Plywood Walls
- (2) 12V LED Loading Lights with Switch
- (2) 2-Way Sidewall Vents (Aluminum)
- (3) Aluminum Ladder Rack Sections
Specifications
| NMA46SA | NMA58SA | NMA510SA | GSA8524TA2 | NMA512SA | NMA610SA | NMA612SA | NMA614SA | NMA612TA2 | NMA614TA2 | NMA712TA2 | NMA714TA | NMA716TA2 | NMA718TA2 | NMA8516TA2 | NMA8518TA2 | NMA8520TA2 | NMA8522TA2 | NMA8524TA2 | NMA8526TA3 | NMA8528TA3 | |
| GVWR: | 2000 lb. | 2990 lb. | 2990 lb. | 7000 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 9800 lb. | 9800 lb. |
| Payload Capacity: | 1510 | 2240 | 2140 | 2975 | 2065 | 2040 | 1990 | 1915 | 5600 | 5500 | 5425 | 5350 | 5250 | 5150 | 4800 | 4700 | 4600 | 4500 | 4300 | 6900 | 6700 |
| Exterior Length: | 10' 0" | 12' 0" | 14' 0" | 28' 0" | 16' 0" | 14' 0" | 16' 0" | 18' 0" | 16' 0" | 18' 0" | 16' 0" | 18' 0" | 20' 0" | 22' 0" | 20' 0" | 22' 0" | 24' 0" | 26' 6" | 28' 0" | 30' 0" | 32' 0" |
| Exterior Width: | 5' 5" | 6' 10" | 6' 10" | 8' 6" | 6' 10" | 7' 10" | 7' 10" | 7' 10" | 7' 10" | 7' 10" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" |
| Exterior Height: | 6' 1" | 6' 8" | 6' 8" | 8' 4" | 6' 8" | 7' 11" | 7' 11" | 8' 0" | 8' 0" | 8' 0" | 8' 1" | 8' 1" | 8' 2" | 8' 2" | 8' 10" | 8' 10" | 8' 10" | 8' 10" | 8' 10" | 9' 0" | 9' 0" |
| Interior Length: | 7' 8" | 9' 8" | 11' 8" | 24' 0" | 13' 8" | 11' 8" | 13' 8" | 15' 8" | 13' 8" | 15' 8" | 13' 8" | 15' 8" | 17' 8" | 19' 8" | 17' 8" | 19' 8" | 21' 8" | 23' 8" | 25' 8" | 27' 8" | 29' 8" |
| Interior Width: | 3' 9" | 4' 9" | 4' 9" | 8' 0" | 4' 9" | 5' 9" | 5' 9" | 5' 9" | 5' 9" | 5' 9" | 6' 9" | 6' 9" | 6' 9" | 6' 9" | 8' 1" | 8' 1" | 8' 1" | 8' 1" | 8' 1" | 8' 1" | 8' 1" |
| Interior Height: | 4' 3" | 5' 0" | 5' 0" | 6' 5" | 5' 0" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 1" | 6' 7" | 6' 7" | 6' 7" | 6' 7" | 6' 7" | 6' 7" | 6' 7" |
| Rear Door Type: | Single Swing | Double Door | Double Door | Ramp | Double Door | Double Door | Double Door | Double Door | Double Door | Double Door | Double Door | Double Door | Double Door | Double Door | Ramp | Ramp | Ramp | Ramp | Ramp | Ramp | Ramp Door |
| Rear Door Width: | 3' 3" | 4' 3" | 4' 3" | 7' 6" | 4' 3" | 5' 4" | 5' 4" | 5' 4" | 5' 4" | 5' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 7' 8" | 7' 8" | 7' 8" | 7' 8" | 7' 8" | 7' 8" | 7' 8" |
| Rear Door Height: | 3' 10" | 4' 9" | 4' 9" | TBD | 4' 9" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 5' 10" | 6' 8" | 6' 8" | 6' 8" | 6' 8" | 6' 8" | 6' 8" | 6' 8" |
| Coupler Size: | 2" | 2" | 2" | 2 5/16" | 2" | 2" | 2" | 2" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" |
| Curb Weight: | 490 | 750 | 850 | 4025 | 925 | 950 | 1000 | 1075 | 1400 | 1500 | 1575 | 1650 | 1750 | 1850 | 2200 | 2300 | 2400 | 2500 | 2700 | 2900 | 3100 |
| Hitch Weight: | 58 | 90 | 102 | 410 | 111 | 114 | 120 | 129 | 168 | 180 | 189 | 198 | 210 | 222 | 264 | 276 | 288 | 300 | 324 | 348 | 372 |
| Hitch Height: | 13" | 14" | 14" | 16" | 14" | 14" | 14" | 15" | 15" | 15" | 19" | 19" | 20" | 20" | 18" | 18" | 18" | 18" | 18" | 19" | 19" |
| Platform Height: | 16 | 18 | 18 | 18 | 18 | 18 | 18 | 19 | 19 | 19 | 22 | 22 | 23 | 23 | 21 | 21 | 21 | 21 | 21 | 23 | 23 |
| Axle: | 1-2000 lbs | 2990 | 1-3500 | 2-3500 lbs | 1-3500 lbs | 1-3500 lbs | 1-3500 lbs | 1-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-3500 lbs | 2-5200 lbs | 2-5200 lbs |
| Suspension: | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD |
| Brakes: | No | Optional | Optional | Electric | Optional | Optional | Optional | Optional | Electric | Electric | Electric | Electric | Electric | Electric | Standard | Standard | Standard | Standard | Standard | Standard | Standard |
| Tires: | 530/12 | ST205/75D15 | ST205/75D15 | ST205/75R15LRC | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST205/75D15 | ST225/75D15 | ST225/75D15 |
| Wheels: | 4-Bolt Steel | 5-Bolt Steel | 5 Bolt Steel | 5-Bolt | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 5 Bolt Steel | 6 Bolt Steel | 6 Bolt Steel |
| Main Frame: | 2" x 3" Tube | 2" x 3" Tube | 2" x 3" Tube | 2 x 7 Dbl Hollow | 2" x 3" Tube | 2" x 3" Tube | 2" x 3" Tube | 2" X 4" Tube | 2" x 4" Tube | 2" x 4" Tube | 2" x 4" Tube | 2" x 4" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 5" Tube | 2" x 7" Tube | 2" x 7" Tube |
| Floor: | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood |
| Walls: | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood |
