Lancer
Feature packed reliable design. For the budget conscious traveler.
---edit.jpg)
---edit.jpg)
---edit.jpg)
-
- Steel Framed Walls, Floor & Roof
- Double Rear Doors
- Semi Style Camlock Door Latch on Rear Doors
- Leaf-Spring Axles
- All-Wheel Electric Brakes w/Breakaway*
- 12-Volt Breakaway Switch with Battery*
- Silver Powder Coated Wheels
- Black Center Caps
- Radial Tires
- Galvanized Roof
- C/S Door (24" on 5 wide, 32" on 6 wide, 36" on 7 & 8 wide)
- 12" Stoneguard
- 1 – Interior LED Dome Light
- 3/8" Engineered Wood Paneling On Walls (24" o/c)
- 3/4 Plywood Floor (24" o/c)
- ATP Exterior Aluminum Fenders
- Clear Lens LED Clearance Lights
- Clear Lens LED Strip Tail Lights
- .030 White Aluminum Exterior (Additional Charge for Color)
- Black, Charcoal, Diamond Ice And Red Exterior Colors Available
- Aluminum Wrap on Rear Corners & Header
- Undercoated Frame
- Tongue Jack w/ Sand Pad
- Welded Safety Chains
- Steel Sealed Sidewalls
Specifications
| LN58SA | LN510SA | LN610SA | LN612SA | LN714TA2 | LN716TA2 | LN816TA2 | |
| GVWR: | 2990 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 7000 lb. | 7000 lb. | 7000 lb. |
| Payload Capacity: | 2160 | 2090 | 1965 | 1890 | 5080 | 4780 | 4600 |
| Exterior Length: | 11' 10" | 13' 10" | 13' 10" | 15' 10" | 17' 10" | 19' 10" | 19' 10" |
| Exterior Width: | 6' 10" | 6' 10" | 7' 10" | 7' 10" | 8' 6" | 8' 6" | 8' 6" |
| Exterior Height: | 6' 6" | 6' 6" | 7' 6" | 7' 6" | 7' 8" | 7' 8" | 8' 2" |
| Interior Length: | 8' 5" | 10' 5" | 10' 5" | 12' 5" | 14' 5" | 16' 5" | 16' 5" |
| Interior Width: | 4' 9" | 4' 9" | 5' 9" | 5' 9" | 6' 8" | 6' 8" | 7' 6" |
| Interior Height: | 4' 11" | 4' 11" | 5' 11" | 5' 11" | 6' 2" | 6' 2" | 6' 4" |
| Rear Door Type: | Single | Single | Double | Double | Double | Double | Double |
| Rear Door Width: | 4' 4" | 4' 4" | 5' 4" | 5' 4" | 6' 4" | 6' 4" | 7' 1" |
| Rear Door Height: | 4' 5" | 4' 5" | 5' 5" | 5' 5" | 5' 9" | 5' 9" | 5' 11" |
| Coupler Size: | 2" | 2" | 2" | 2" | 2-5/16" | 2 5/16" | 2 5/16" |
| Curb Weight: | 830 | 900 | 1025 | 1100 | 1920 | 2120 | 2400 |
| Hitch Weight: | 80 | 90 | 120 | 120 | 210 | 240 | 250 |
| Hitch Height: | 16" | 16" | 17" | 17" | 18" | 18" | 20" |
| Platform Height: | 17 | 17 | 17 | 17 | 19 | 19 | 21 |
| Axle: | 2990 | 2990 | 2990 | 2990 | 3500 | 3500 | 3500 |
| Suspension: | TBD | TBD | TBD | TBD | TBD | TBD | TBD |
| Brakes: | N/A | N/A | N/A | N/A | Electric | Electric | Electric |
| Tires: | ST205/75R15 | ST205/75R15 | ST205/75R15 | ST205/75R15 | ST205/75R15 | ST205/75R15 | ST205/75R15 |
| Wheels: | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt |
| Main Frame: | 3" Tube | 3" Tube | 3" Tube | 3" Tube | 4" Tube | 4" Tube | 6" I Beam |
| Floor: | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood |
| Walls: | 3/8" Eng. Wood | 3/8" Eng. Wood | 3/8" Eng. Wood | 3/8" Eng. Wood | 3/8" Eng. Wood | 3/8" Eng. Wood | 3/8" Eng. Wood |
