Explore Nomad
Nomad
Uncompromised quality at an affordable price. Wherever you wander, Nomad will stay behind you.
---edit.jpg)
.jpg)
.jpg)
-
- Double Rear Doors
- 18" Wedge-Front Nose
- C/S Door (24" on 5 wide, 32" on 6 wide, 36" on 7 & 8 wide)
- Semi-Style Camlock Door Latch
- Door Hold-Back on Rear Door
- Leaf-Spring Axle
- Silver Powder Coated Wheels
- Radial Tires
- Galvanized Roof
- Aluminum Top Rails
- 16" ATP Stoneguard
- 1 – 12V LED Dome Light
- 2 - Flow Thru Sidewall Vents
- DOT Lighting
- Aluminum Exterior Fenders
- Clear Lens LED Clearance Lights
- Clear Lens LED Strip Tail Lights
- License Plate Holder with Built-In Light
- .030 White Aluminum Exterior
- ATP Aluminum Wrap on rear
- Exposed Steel Painted Epoxy Black
- Undercoated Frame
- Tongue Jack w/ Sand Pad
- Welded Safety Chains
- Full-Color Decals
- 8'6" Wides include:
- 102" Wide Body Design
- Ramp Door with Spring Assist
- No-Show Beavertail
- 36" Side Door with Steel Step
- 2-12 Volt LED Dome Lights
- 1-Roof Vent in addition to Side Vents
-
- 16" O/C Roof Upgrade
- One-Piece Aluminum Roof
- 36" RV Door Upgrade (No Window or Screen)
- (2) LED Loading Lights with switch
- (2) Stabilizer Jacks Under Rear Corners
- 6" of ATP Along Exterior Bottom of Sidewalls
-
- 24" Aluminum Tread Plate Stoneguard Upgrade
- 1 - LED Dome Light (total of 2)
- 1 - 12 Volt Switch for LED Domes
- Flushlock
-
- Rear Ramp Door
- 24" Aluminum Tread Plate Stoneguard Upgrade
- 1 - LED Dome Light (total of 2)
- 1 - 12 Volt Switch for LED Domes
- 1 Pair Stabilizer Jacks
-
- 24" Aluminum Trade Plate Stoneguard Upgrade
- 3 - LED Dome Light (total of 4)
- 2 - 12 Volt Switches for LED Domes
- 16" O/C Floor Crossmembers
-
- 6" Extra Height
- Rear Ramp Door
- 1 Pair Stabilizer Jacks
- 4-Surface Mount D-Rings
-
- 16" O/C Roof
- 16" O/C Floor Members
- 60" Triple Tube Tongue
- 3/4" Plywood Walls
- (2) LED Loading Lights with switch
- (2) 2-Way Sidewall Vents (Aluminum)
- (3) Aluminum Ladder Rack Sections
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (2) Non-Powered Roof Vents
- 48" Side Door with Flushlock
- 54" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
- Surface Wall Mount E-Track (1 Row on Each Sidewall)
- Shelf Across Front of Trailer (24" Deep with 3" Lip)
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (1) Non-Powered Roof Vent
- 54" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- 16" O/C Roof Upgrade
- Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
-
- (2) 2-Way Sidewall Vents (Aluminum)
- (1) Non-Powered Roof Vent (Total of 2)
- 60" Extended Triple-Tube Tongue
- 16" O/C Floor Upgrade
- 16" O/C Roof Upgrade
- Reinforced Rear Ramp Door with Spring Assist
- (2) 12V LED Dome Lights (Total of 4)
- (1) Wall Switch (Total of 2)
- Extra Grab Handle on Rear Ramp Door
- 3/4" Plywood Kickplate on Interior Walls
- Surface Mount E-Track on Sidewalls, 1 Row Per Wall
- Locking Hasps on Side and Rear Doors
Specifications
| NM46SA | NM58SA | NM510SA | NM610SA | NM612SA | NM612TA2 | NM712SA | NM712TA2 | NM714TA2 | NM716TA2 | NM8518TA2 | NM8520TA2 | NM8522TA2 | NM8524TA2 | NM8518TA3 | NM8520TA3 | NM8522TA3 | NM8524TA3 | |
| GVWR: | 2000 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 2990 lb. | 7000 lb. | 3500 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 7000 lb. | 9800 lb. | 9800 lb. | 9800 lb. | 9800 lb. |
| Payload Capacity: | 1251 | 2100 | 1890 | 1790 | 1690 | 5400 | 1900 | 5150 | 5050 | 4900 | 3930 | 3800 | 3670 | 3540 | 6450 | 6320 | 6190 | 6060 |
| Exterior Length: | 9' 10" | 11' 10" | 13' 10" | 13' 10" | 15' 10" | 15' 10" | 15' 10" | 15' 10" | 17' 10" | 19' 10" | 21' 10" | 23' 10" | 25' 10" | 27' 10" | 21' 10" | 23' 10" | 25' 10" | 27' 10" |
| Exterior Width: | 5' 5" | 6' 10" | 6' 10" | 7' 10" | 7' 10" | 7' 10" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" | 8' 6" |
| Exterior Height: | 6' 0" | 6' 7" | 6' 6" | 7' 6" | 7' 6" | 8' 1" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 4" | 8' 4" | 8' 4" | 8' 4" | 8' 4" | 8' 4" | 8' 4" | 8' 4" |
| Interior Length: | 7' 2" | 9' 2" | 11' 2" | 11' 2" | 13' 2" | 13' 2" | 13' 1" | 13' 1" | 15' 1" | 17' 1" | 19' 1" | 21' 1" | 23' 1" | 25' 1" | 19' 1" | 21' 1" | 23' 1" | 25' 1" |
| Interior Width: | 3' 9" | 4' 8" | 4' 8" | 5' 9" | 5' 9" | 5' 9" | 6' 8" | 6' 8" | 6' 8" | 6' 8" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 0" | 8' 0" |
| Interior Height: | 4' 2" | 4' 11" | 4' 11" | 5' 11" | 5' 11" | 6' 5" | 6' 1" | 6' 1" | 6' 1" | 5' 10" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" |
| Rear Door Type: | Single | Double | Double | Double | Double | Double | Double | Double | Double | Double | Ramp | Ramp | Ramp | Ramp | Ramp | Ramp | Ramp | Ramp |
| Rear Door Width: | 3' 1" | 4' 4" | 4' 4" | 5' 4" | 5' 4" | 5' 4" | 6' 4" | 6' 4" | 6' 4" | 6' 4" | 7' 7" | 7' 7" | 7' 7" | 7' 7" | 7' 7" | 7' 7" | 7' 7" | 7' 7" |
| Rear Door Height: | 3' 9" | 4' 5" | 4' 5" | 5' 5" | 5' 5" | 5' 11" | 5' 7" | 5' 7" | 5' 7" | 5' 5" | 6' 2" | 6' 2" | 6' 2" | 6' 2" | 6' 2" | 6' 2" | 6' 2" | 6' 2" |
| Coupler Size: | 2" | 2" | 2" | 2" | 2" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2 5/16" | 2-5/16" | 2 5/16" |
| Curb Weight: | 749 | 890 | 1100 | 1200 | 1300 | 1600 | 1600 | 1850 | 1950 | 2100 | 3070 | 3200 | 3330 | 3460 | 3350 | 3480 | 3610 | 3740 |
| Hitch Weight: | 75 | 90 | 110 | 120 | 130 | 160 | 160 | 185 | 200 | 215 | 310 | 320 | 330 | 340 | 340 | 350 | 360 | 370 |
| Hitch Height: | 20" | 16" | 16" | 16" | 16" | 17" | 18" | 18" | 18" | 20" | 20" | 20" | 20" | 20" | 20" | 20" | 20" | 20" |
| Platform Height: | 20 | 17 | 17 | 17 | 17 | 19 | 19 | 19 | 19 | 19 | 18 | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
| Axle: | 2000 | 2990 | 2990 | 2990 | 299 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 3500 | 5200 | 5200 | 5200 | 5200 |
| Suspension: | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD | TBD |
| Brakes: | N/A | Optional | Optional | Optional | Optional | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric | Electric |
| Tires: | 530/12 | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST205/75R15/C | ST225/75D15/D | ST225/75D15/D | ST225/75D15/D | ST225/75D15/D |
| Wheels: | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 5 Bolt | 6 Bolt | 6 Bolt | 6 Bolt | 6 Bolt |
| Main Frame: | Angle | 3" Tube | 3" Tube | 3" Tube | 3" Tube | 4" Tube | 4" Tube | 4" Tube | 4" Tube | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam | 6" I-Beam |
| Floor: | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood | 3/4" Plywood |
| Walls: | 3/16" Lauan | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood | 3/8" Plywood |
